Features
• Easy installation, low torque and fast expansion
• The extended friction plate adopts the punching process to increase the force area and enhance the friction
• Cold-rolled one-piece molding ensures that the anchor bolt has good plasticity, so that when adjusting the angle,
• It will not break
• Two burial depths for easy selection
• Burial depth marking line for easy on-site inspection
• Tail mark for easy installation inspection
Application
• Elevator guide rail bracket / floor door sill / cable bracket / guardrail frame, etc.
Material, coating | coating Carbon steel, galvanized |
Head setting | External thread |
Certification/test report | Class N, Grade I (as specified in JG145-2013) |
Substrate | Non-cracked concrete |
Drilling method | Impact drilling, Air compression drilling, Hollow drill drilling, Diamond electric drill |
Installation tool | Electric hammer |
Design software | Yes |
Quality inspection | Passed |
Product origin | Huzhou, Zhejiang |
